Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	750 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via IP T-Con (M) mounting version power supply cord with safety plug
Device fuse:	6.3 x 32 mm, 5 A fuse replaceable
Lamp type:	LED lamp
LED type:	1 x 640 W COB (chip-on-board) cold white (CW)
Max. TILT movement:	260° exact positioning (16 bit resolution) auto position correction (feedback)
Max. PAN movement:	540° exact positioning (16 bit resolution) auto position correction (feedback)
Flash rate:	1 - 16 Hz
Equipment:	Prism 4-fold rotating; iris; frost filter linear; zoom motor driven; focus motor-driven; animation wheel; shutter blades motor-driven
Color generation:	CMY+CTO color mixing for indefinite color variations
Color generation:	Color wheel with 8 dichroic filters plus open Rainbow effect with adjustable speed in both directions
Gobos:	Gobo wheel with rotating gobos, 7 gobos and open Outside diameter 30mm Image diameter 22mm Shake effect Gobo indexable Slot-in gobo system for easy gobo replacement Gobo wheel with static gobos, 8 gobos and open Shake effect
DMX channels:	33; 35; 39
DMX input:	5-pin XLR (M) mounting version IP 3-pin XLR (M) mounting version IP
DMX output:	5-pin XLR (F) mounting version IP 3-pin XLR (F) mounting version IP
Cooling:	4 x temperature-controlled fan at the head 2 x temperature-controlled fan at the base
Control:	Stand-alone; master/slave function; DMX; RDM; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); CRMX by LumenRadio upgradeable; W-DMX by wireless solution via USB (optional)
Fixtures available for:	GDTF (GrandMA3)
Projection:	Flicker-free
Beam angle:	10° - 47°
Beam angle (1/2 peak):	10 - 47°
Beam angle (1/10 peak):	10 - 47°
Color rendering index (CRI):	85 Ra via filter
Illuminance in Lux (lx):	Narrow cold white (CW) 3m: 69565 lx, 6m: 19180 lx Wide cold white (CW) 1m: 27924 lx, 3m: 3489 lx, 6m: 1000 lx
Housing color:	Black
Attachment system:	2x omega bracket
Display type:	Multicolor LCD display battery buffering upgradeable
Dimensions:	Width: 44.2 cm Depth: 30.1 cm Height: 75.3 cm
Weight:	37.15 kg
Noise classification:	Class 1 (very slight noise, suitable for noise-sensitive environments)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397726534	41,00 kg	86cm x 54cm x 42cm

Spare parts

Fan 12V/0,16A 60x60x15mm Sunon (ME60151V1-000C-G99)

Fan 12V/1,25A 80x80x25mm (EF80251B1-1000C-G99)

Pcb (Power supply) DMH-640 (VUP1000F42D32B-B)

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Dimensional drawing

Name	Version	Language
51841990-Dimensions-162444-1.0000-51841990dimensionspdf-de.pdf (282 KB)	1.0000	de

Support

Name	Version	Language
51841990-Support-157364-fuer-MA2-de.zip (8 KB)	0.0000	de

All images

Name	Version	Language
51841990-Images-.zip

Publications

Move Magazine #2/2024 E

On page: 89

Size: 14 MB

Move Magazine #1/2024 E

On page: 11

Size: 28 MB

Video link

https://www.youtube-nocookie.com/embed/TXx1cnEkMV8

FUTURELIGHT DMH-640 Profile CMY Moving Head Spot

Double tap or pinch to zoomHover to zoom

Bildergalerie öffnen

Detail images (23 overall)

FUTURELIGHT DMH-640 Profile CMY Moving Head Spot

Stock for approx. 12 wk(s)

Priceon demand

Find a dealer

Stock for approx. 12 wk(s)

Due to the dimensions of this article, different shipping conditions apply.

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51841990

10 - 47°

Profile moving head with 640 W COB LED, motorized shutter blades, large zoom, CMY+CTO color mixing and animation wheel

1 LED 640 W COB (chip-on-board) cold white (CW)
Positioning within 540° PAN, 260° TILT
Auto position correction (feedback)
Exact positioning (16 bit resolution)
Exact 16 bit resolution at Dimmer, zoom, focus, gobo rotation
Prism 4-fold rotating; iris; frost filter linear; zoom motor driven; focus motor-driven; animation wheel; shutter blades motor-driven
Pulse-width modulation variable
CMY+CTO color mixing for indefinite color variations
Color wheel with 8 dichroic filters plus open
rainbow effect with adjustable speed in both directions
Gobo wheel with rotating gobos, 7 gobos and open
shake effect
Gobo indexable
Slot-in gobo system for easy gobo replacement
Gobo wheel with static gobos, 8 gobos and open
shake effect
The device is cooled by temperature-controlled fan at the head; temperature-controlled fan at the base
Control via stand-alone; master/slave function; DMX; RDM; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); CRMX by LumenRadio upgradeable; W-DMX by wireless solution via USB (optional)
Fixtures available for GDTF (GrandMA3)
Flicker-free
With a beam angle of 10° - 47°
Good color rendering index (CRI)
With omega bracket
Multicolor LCD display,
with battery buffering for easy controlling upgradeable
For application areas such as: Wedding/gala/events; stage; theater; rental; Trade fair and shop fitting; video and photography
Very quiet working noise
Application possibility: Standing; suspended

Technical specifications

Spare parts

User manual

Downloads

Manufacturer information

Scope of delivery

Save money: This article is available in a bundle.

FUTURELIGHT Set 2x DMH-640 Profile CMY + Case with wheels

Priceon demand

Accessories

Loading accessories. Please wait...

FUTURELIGHT DMH-640:

Powerful LED moving spotlight

With the DMH-640, Futurelight offers an LED moving spotlight that impresses in terms of performance and features. This versatile device is suitable for a wide range of applications, from live concerts to theater productions.

Features

The DMH-640 has a 640-watt LED that provides high light output. With CMY color mixing, frost filter and two gobo wheels, the DMH-640 offers a wide range of creative possibilities.

The CMY color mixing enables smooth color transitions and an almost unlimited selection of colors. In addition, the gobo wheels create impressive visual effects that give every show that certain something.

Shutter sliders and zoom

Four motorized shutters can precisely limit the light by means of retractable and rotatable shutters, which is particularly advantageous for theatrical applications. The zoom range extends from 10° to 47°, allowing the DMH-640 to be used flexibly for various lighting scenarios: from narrow beams to wide wash effects.

Application

The DMH-640 is designed for use in fog as well as for projections. When selecting the gobos, care was taken to ensure that both impressive projections and clear structures in the fog are possible. With its CRI filter and very quiet operation, the moving head is therefore a good choice for a wide range of applications, including live events, theater productions and installations.

Connections

The DMX connections are both 3-pin and 5-pin, allowing flexible integration into existing lighting systems.The power connection is made via T-Con.
