Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Protection class:	Protection class I
Power connection:	Battery/battery pack Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:	1 x P-Con (gray), mounting version
Battery pack type:	1 x lithium ion 11.1 V, 10400 mAh, 115.44 Wh
Lamp type:	LED lamp
LED type:	6 x 8 W SMD 9080 4in1 RGBW (homogenous color mix)
DMX channels:	4; 6; 8; 11; 12; 13; 17; 24; 29
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Passive convection cooling
Control:	Stand-alone; DMX; master/slave function; sound to light via microphone; IR remote control; W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional)
Fixtures available for:	LED PC-Control 512; EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; Light´J; Light Captain; EASY SHOW 2; EASY SHOW 3; Colorchief
Projection:	Flicker-free
Beam angle (1/2 peak):	8°
Beam angle:	8°°
Beam angle (1/10 peak):	17°
Housing color:	Black
Attachment system:	Double bracket
Dimensions:	Length: 50.2 cm Depth: 6 cm Height: 20.1 cm
Weight:	3.80 kg
Noise classification:	Class 0 (no noise at all)
Remote control
Battery:	1 x button cell 3.0 V CR2032 lithium manganese built-in
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397673364	4,27 kg	56cm x 13cm x 26cm
4	4026397673982	18,35 kg	58cm x 55cm x 30cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
41700122-Support-129092-10.000-41700122-LED-PC-Control-Fixture-en.zip (12 KB)	10.000	en
41700122-Support-136592-Fixture-fuer-Colorchief-V2x-de.zip (219 B)	0.0000	de

All images

Name	Version	Language
41700122-Images-.zip

Publications

On page: 46

Size: 28 MB

Video link

EUROLITE AKKU Bar-6 QCL

The article is no longer in our assortment.

No. 41700122

8°

Battery-powered LED bar with 4in1 LEDs and IR remote control

Additional frost filter provides a wide, soft and homogeneous light
Cordless, flexible and versatile
Integrated automatic charging of the battery and status indicator
6 LEDs 8 W SMD 9080 4in1 RGBW (homogenous color mix)
LEDs controlled separately
Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic; Dimmer speed (step response) adjustable
Strobe effect
Integrated show programs
Direct color selection for 35 preset colors
Can be operated in 4; 6; 8; 11; 12; 13; 17; 24; 29 CH mode
The device is cooled by passive convection cooling
Control via stand-alone; DMX; master/slave function; sound to light via microphone; IR remote control; W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional)
Flicker-free
With a beam angle of 8°
With double bracket
Mains input and output for power linking up to 8 units
For application areas such as: Wedding/gala/events; mobile use; mobile djs / entertainer; small rental
Silent operation
Application possibility: Standing; suspended; on stand
