Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	130 W
IP classification:	IP20
Power connection:	Fixed power supply cord with safety plug
Lamp type:	LED lamp
LED type:	1 x 100 W COB (chip-on-board) 3in1 TCL RGB (homogenous color mix)
DMX channels:	3; 5
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Control:	DMX; sound to light via microphone
Fixtures available for:	EASY SHOW 1; LED PC-Control 512; Light´J; EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE
Beam angle:	40°
Beam angle (1/2 peak):	40°
Housing color:	Silver
Dimensions:	Width: 24 cm Depth: 36.5 cm Height: 31.5 cm
Weight:	2.6 kg
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397454253	3,00 kg	24cm x 24cm x 44,5cm
4	4026397454260	13,70 kg	50,5cm x 50,5cm x 46,5cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
41607245-Support-105646-1.0000-41607220-LED-PC-Control-fixtures-de.zip (1 KB)	1.0000	de
41607245-Support-136438-Fixture-fuer-Colorchief-V2x-de.zip (223 B)	0.0000	de

Press report

Name	Version	Language
41607245-Press-70592-SC72012cobpdf-de_en_es_fr.pdf (2 MB)	0.0000	de_en_es_fr
41607245-Press-71928-1.0000-en_es_fr.pdf (181 KB)	1.0000	en_es_fr
41607245-Press-71929-1.0000-de.pdf (188 KB)	1.0000	de
41607245-Press-71930-1.0000-en_es_fr.pdf (177 KB)	1.0000	en_es_fr
41607245-Press-71931-1.0000-de.pdf (184 KB)	1.0000	de
41607245-Press-71932-1.0000-en_es_fr.pdf (48 KB)	1.0000	en_es_fr

Data sheet

Name	Version	Language

Video file

Name	Version	Language
41607245-Video-70795-de_en_es_fr.flv (20 MB)	0.0000	de_en_es_fr

All images

Name	Version	Language
41607245-Images-.zip

Video link

EUROLITE LED PAR-56 COB RGB 100W sil

The article is no longer in our assortment.

No. 41607245

40°

PRO spotlight as DMX model with COB LED

Equipped with a powerful RGB 100 W COB LED
Functions: static colors, RGB color mixture, internal programs, dimmer and strobe settings via DMX, Master/Slave
Dimmer speed (step response) adjustable
Operable in stand-alone mode or with DMX interface
Adjustable microphone sensitivity via LCD display
Comfortable addressing and setting via control panel with LCD display and four operating buttons
Locking possibility at the mounting bracket
With color filter frame
Ready for connection via power cord with safety-plug
Available in silver or in black
1 LED 100 W COB (chip-on-board) 3in1 TCL RGB (homogenous color mix)
Strobe effect
Control via DMX; sound to light via microphone
Fixtures available for EASY SHOW 1; LED PC-Control 512; Light´J; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE
With a beam angle of 40°
For further information about this product, please refer to the Data Sheet under "Downloads"
