Technical specifications
Power supply:
115/230 V AC, 50/60 Hz
Power consumption:
3500.00 W
Output power:
625 W RMS (8 ohms)
Dimensions:
Width: 48.3 cm
Depth: 49 cm
Height: 8.9 cm
Weight:
17.20 kg
Power range:
230 V ±10 % (207-253 V)
Power output sine:
Stereo 4 ohms
2 x 1000 W
Stereo 8 ohms
2 x 625 W
8 ohms bridged
1 x 1875 W
Frequency range:
40-40000 Hz, ±3 dB
Damping factor:
>400
Distortion factor:
0.01 %
Signal-to-noise ratio:
90 dB
Channel seperation (at 1 kHz):
70 dB
Min. input sensitivity:
0.77 V/26 dB/1.4 V
Input impedance:
20 kohms (balanced)
Slew rate:
60 V/µsec
Input connectors:
2 x XLR female plug, 2 x 6.3 mm jack plug
Output connectors:
2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination
Control elements:
Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter
LED indicators (per channel):
Power, Protect, Signal, Mode
Protection circuits:
Short-circuit, DCt, thermal, softstart
Construction:
Steel chassis, aluminum front panel
Minimum mounting depth:
510 mm
Packaging units
PU
EAN
Weight
Dimensions
1
4026397145861
18,50 kg
51cm x 49cm x 15cm
Spare parts
Diode 1N 4148 100V 200mA 4ns
Transistor A 1837
Transistor C 4793
Transistor D 667A
Transistor B 647
Transistor 2SD 667
Resistor 0,47 Ohm 5W Radial Leaded metal layer
Downloads
Spezifications
Name
Version
Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral
Illustration
Name
Version
Language
10451180-Illustration-8030-en.pdf (4 MB)
0.0000
en
0.0000
en
0.0000
en
0.0000
en
0.0000
en
0.0000
en
0.0000
de
Press report
Name
Version
Language
0.0000
de_es
Service document
Name
Version
Language
10451180-Service-5786-2.0000-de.pdf (169 KB)
2.0000
de
All images
Name
Version
Language
10451180-Images-.zip
...
Audio
/
Amplifier
/
Amplifiers
OMNITRONIC P-2000 Amplifier, 2x1000W/4ohm
Double tap or pinch to zoom
Hover to zoom
Bildergalerie öffnen
Detail images (2 overall)
OMNITRONIC P-2000 Amplifier, 2x1000W/4ohm
The article is no longer in our assortment.
No. 10451180
Powerful PA amplifier for large stages
2 x 1000 W/4 ohm
Enormous power with highest brilliance
2 gain controls on the front panel
All operation modes controllable via LEDs
LED intensity adjustable via brightness control on the rear panel
Signal inputs via XLR female or 6.3 mm jack socket
Input sensitivity adjustable via selector on the rear panel
Speaker connection via lockable Speaker plugs or Banana/screw combination
With limiter
Ground Lift switch against humming
Bridged switch for bridging
Many protection circuits for optimized equipment protection
Very rugged housing
Rack installation
High power/weight-relation
